Standalone access controller and wiegand 26 reader A8-D
Description
1.This unit is single door multi-function standalone access controller or a Wiegand 26 output keypad card reader.
2.It is suitable for mounting either indoor or outdoor in harsh environments. It is housed in a strong, sturdy and vandal proof Zinc Alloy electroplated case .
3.The electronics are fully potted so the unit is waterproof and conforms to IP67.
4.This unit supports up to 2000 users in either a Card, 4 to 8 digit PIN, or a Card + PIN option.
5.The inbuilt card reader supports 125KHZ EM cards. The unit has many extra features including a backlight keypad. These features make the unit an ideal choice for door access not only for small shops and domestic households but also for commercial and industrial applications such as factories, warehouses, laboratories, banks and prisons.
Features
|
Operating Voltage
|
DC 10-24V±10%
|
|
User Capacity
|
2000 Cards
|
|
Reading Distance
|
3-6 cm depends on cards or tags
|
|
Active Current
|
<80mA
|
|
Idle Current 35mA
|
<40mA
|
|
Lock Output Load
|
≤2A
|
|
Operating Temperature
|
-45℃～70℃
|
|
Operating Humidity
|
10%- 90%
|
|
Dimensions
|
L129xW44xH20mm
|
|
Weight
|
410G
|
|
Waterproof rate
|
IP67
|
