12V 4CH wireless RM remote control Switch

  • 12V 4CH wireless RM remote control Switch
  • 12V 4CH wireless RM remote control Switch
  • 12V 4CH wireless RM remote control Switch
  • 12V 4CH wireless RM remote control Switch
  • 12V 4CH wireless RM remote control Switch
  • 12V 4CH wireless RM remote control Switch
  • 12V 4CH wireless RM remote control Switch
  • 12V 4CH wireless RM remote control Switch
Model No.︰RM06
Brand Name︰Dwell
Country of Origin︰China
Unit Price︰-
Minimum Order︰1 pc
Share on:

 Total 24 Related Items
Prev2021222324

Product Description

315Mhz DC12V 4CH Remote Control Switch RM06



Receiver Specifications

1) Supply Voltage 12V DC

2) Static Current =< 6mA

3) Frequency 433 MHz

4) Sensitivity >= -105 dB

5) Relay Spec. 10A, 120VAC / 10A, 24V DC

6) Operating Temperature -40 to 80 deg C

7) Dimension: 22x30x11mm

8) Weight (with housing) 2.5 oz






Transmitter (Remote) Specifications

1) Battery Voltage: 12V (1 piece)

2) Dimension: 15x25x5mm

3) Weight (with battery): 1.2 oz

4) Range: 20-100m





Application



Garage doors, appliances switches or other areas of wireless control




Load Type

Fluorescent energy saving lamp LED light load motor ...... etc.


 Output

Relay common / normally open / normally closed


Four Control Channels :

A.Self-locking control mode Click the button corresponding relay switches in the same key , click the
corresponding relay is switched off , ABCD four independently -off .


B.Jog type control mode : Long press buttons corresponding relay switches , release the button
corresponding to the relay is switched off , 4-way can not work independently , each only way to work ;


C.Interlocked control mode: Press the A button A and lock has been switched on, press the B button to

disconnect A , B and lock has been switched on, press the C key to disconnect the B, C Lu has been turned

ON and locked press the D key to disconnect C, D Road has been turned on and turned the lock , you can

only turn all the way , and as fans gear . )
Tips: Remote control buttons Press only one button can not hold down two or more keys simultaneously ,

otherwise it will affect the normal work of mutual interference .


D Learning code mode :

Click the button to learn , indicator lights , release the button to learn , within 15 seconds, press any button on the remote control , the receiver learn LED flash , remote control and receiver success of the code . after 15 seconds if no transmitter signal is input to learn,learn about LED flash , auto- exit learning state , supports up to 30 different remote control code
learning the code , when learning to 31 remote will automatically clear the first remote control
controller .


E.Clear the right code ;

Tight hold button and hold the receiver to learn , learning indicator
lights After about 8 seconds , until the learn indicator light goes out , release the learn button ,
remove all code learning remote control.

Payment Terms︰tt,western union , paypal , Escrow,Cash
